If you’ve ever wanted to add vibrant, customizable lighting to your home, WLED is one of the best ways to do it. I’ve written many articles about my use of WLED for accent lighting, ambient room effects, dazzling holiday displays, and security lighting. WLED provides powerful, easy-to-use controls for LED strips and strings.
Years ago I wrote an article about how to get going with WLED in 10 minutes. However, that was using controllers you put together yourself. Things have gotten even easier now. Let’s go through the easiest way to set up a WLED-powered LED system—covering controllers, power supplies, LED selection, and power injection.
This page contains affiliate links. If you purchase an item using an affiliate link I will receive a small commission at no cost to you. Affiliates do not influence my recommendations. Read my disclosures for more information.
Table of Contents
Toggle
The easiest way to start with WLED is to buy a pre-configured controller that already has WLED installed. This saves you time and effort compared to flashing firmware onto ESP-based boards yourself.
Best Pre-Flashed WLED Controllers You Can Buy
Athom WLED Controller – A compact, reliable option that works out of the box.
QuinLED-Dig-Uno – A high-quality, beginner-friendly option with good power handling.
Various WLED-powered controllers on Amazon – Amazon has many inexpensive WLED controllers.
Editor’s Note: Be sure to check out my WLED hardware guide for pre-built WLED controller recommendations.
These controllers connect via Wi-Fi and allow you to control your LED setup through the WLED web interface, an app, or even Home Assistant.
Pro Tip: If you’re comfortable with DIY, you can buy an ESP8266 or ESP32 board and flash WLED onto it yourself for a cheaper, custom solution.
LED strips and strings require stable and sufficient power to function correctly. Choosing the right power supply depends on voltage and amperage needs.
Common WLED Power Supply Options
5V Power Supplies – Used for most WS2812B LED strips but require careful power injection.
12V Power Supplies – Used for WS2815 and some other LED types, allowing longer runs with fewer power issues.
24V Power Supplies – Rare but useful for longer LED runs (e.g., WS2811 pixels).
How to Calculate Power Needs
A general formula to determine the power required is:
Total Power (W) = LEDs per meter × Meters of strip × Power per LED(W)
Then, divide this by the voltage (5V, 12V, or 24V) to determine the amperage needed.
Example: A 5-meter WS2812B (5V) strip (30 LEDs per meter) consumes 0.3W per LED:
Total Power: 5m × 30 LEDs/m × 0.3W = 45W
Amps Needed: 45W ÷ 5V = 9A power supply required
To be safe, choose a power supply that provides at least 20% more power than you need.
Types of Addressable LED Strips
The most common WLED-compatible LED types include:
WS2812B (5V) – Popular, individually addressable LEDs; best for small-scale projects.
WS2815 (12V) – Similar to WS2812B but has backup data lines (great for reliability).
SK6812 (5V) – Similar to WS2812B but supports white LEDs (RGBW).
WS2811 (12V/24V) – Best for LED pixel strings, often used for holiday lighting.
LED Density Considerations
30 LEDs per meter – Low-density, great for ambient lighting.
60 LEDs per meter – Mid-range, balanced power usage and brightness.
144 LEDs per meter – Ultra-bright, requires careful power management.
Pro Tip: For outdoor applications, use weatherproof (IP65 or higher) LED strips.
When using long LED strips (typically over 2-3 meters for 5V, or 5 meters for 12V), voltage drop can cause dim LEDs and flickering. Power injection solves this problem by supplying power at multiple points along the strip.
When to Use Power Injection
If the end of your LED strip is dimmer than the beginning.
If your LED strip flickers or behaves erratically.
If you are running a 5V strip longer than 3 meters or a 12V strip longer than 5 meters.
How to Inject Power
To inject power:
Run extra power wires from the power supply to a midpoint or endpoint of the LED strip.
Connect only the 5V/12V and GND wires (NOT the data line).
Ensure good grounding between all power sources.
Pro Tip: Use thicker gauge wire (16-18 AWG) for power injection to minimize voltage loss.
Getting started with WLED doesn’t have to be intimidating. By using a pre-configured WLED controller, selecting the right power supply, and managing power injection, you’ll be up and running in no time.
Quick Recap
Buy a pre-flashed WLED controller to save time.
Choose a reliable power supply with at least 20% headroom.
Pick the right LED type (WS2812B, WS2815, etc.).
Use power injection for longer LED runs to avoid dimming issues.
Remember to check out my WLED hardware guide for the right equipment.
With these tips, you’ll bring your smart lighting ideas to life with WLED!
Got any questions or need recommendations? Drop a comment below, or check out my other articles on home automation and WLED! 🚀
